LC/APC to LC/APC Single Mode Duplex Fiber Patch Cord
SUPER FLASH
Regular price
Dhs. 17.00
100% satisfaction guaranteed with every order!
Achieve superior signal reflectivity control and maximum port density in your high-bandwidth optical networks with the professional LC/APC to LC/APC Single Mode Duplex Fiber Patch Cord. Engineered with 8-degree Angle Physical Contact (APC) green connectors, this cable is specifically designed for applications that demand minimal back reflection, such as FTTx deployments, CATV systems, passive optical networks (PON), and high-capacity telecommunication infrastructure. The small form-factor LC design doubles your rack port density while maintaining exceptional optical integrity.
Built with premium 9/125μm single-mode optical fiber, this duplex jumper facilitates reliable, bi-directional signal transmission over extended distances with minimal attenuation. The 8-degree angled ceramic ferrule forces reflected light back into the cladding rather than reflecting it toward the laser source, resulting in an exceptional return loss rating exceeding 60 dB. Encased in a flexible, flame-retardant outer jacket, the cable offers strong mechanical protection against physical stress while ensuring effortless routing through cramped server racks and enterprise wiring closets.
To fit your exact layout parameters, this patch cord is available in a comprehensive range of precision lengths, including 1.5M, 3M, 5M, 10M, 15M, 20M, 25M, 30M, 40M, and 50M. Each unit undergoes strict factory testing and inspection to guarantee plug-and-play reliability and immediate deployment readiness.
Key Specifications & Features
- Connector Type: LC/APC to LC/APC (Green Duplex configuration)
- Fiber Type: Single Mode 9/125μm (G.652D / G.657A1 compatible)
- Available Lengths: 1.5M, 3M, 5M, 10M, 15M, 20M, 25M, 30M, 40M, and 50M
- Insertion Loss: ≤ 0.3 dB
- Return Loss: ≥ 60 dB (APC 8° Polish)
- Ferrule Material: High-precision Ceramic
- Jacket Material: PVC / LSZH (Low Smoke Zero Halogen)
Explore Related Fiber Optic Solutions
Looking for alternative configurations or complete infrastructure products? Explore our full catalog through our Fiber Optic Cables Collection. You may also be interested in these related products:
Planning a Bulk Purchase or Commercial Deployment?
We offer special wholesale pricing, custom lengths, and fast fulfillment for enterprise and contractor orders across the UAE.
Frequently Asked Questions (FAQs)
1. What is the advantage of an LC/APC connector over UPC?
APC connectors feature an 8-degree angle polish that significantly reduces back reflection (return loss), making them ideal for high-sensitivity optical systems and FTTx networks.
2. Can I connect an LC/APC cable to an LC/UPC port?
No, APC and UPC connector polishes should not be mated together as the physical mismatch can damage the fiber end-faces and cause severe insertion loss.
3. What length variations are available for this patch cord?
We supply this duplex patch cord in standard precision lengths including 1.5M, 3M, 5M, 10M, 15M, 20M, 25M, 30M, 40M, and 50M.
4. Is this cable suitable for high-density rack configurations?
Yes, the compact small form-factor LC latch design maximizes port density, making it perfect for crowded server racks and enterprise patch panels.
